AeroInsert-H for 0.244"-0.246" ID Arrows (12)

AeroInsert H for 0.244" class ID (AIH24A/S) is specially made to fit 0.244 - 0.246" ID shaft like Firenock AeroWeave 246 and is available in many material and weight. This dual patented design is which provides self-concentricity, reliability, and harmonic dampening to the arrow shafts to address the need for any high-performance archery projectile.

Note: AIH24/S must use with Carbon Inner Tube CTI240 to form AeroConcept System to perform its designed result.  For non-carbon tube inserts, please look into AIA24A/S inserts.

Features of AeroInsert H:

• Self Concentric Technology
• Double Shoulder Technology
• Extra-large adhesive surface for strength and stability
• AeroConcept System ready
• CNC machined for extra hardness and accuracy
• Designed in US Illinois and US Patented (#8337342, and #8403777)

Contents:

• 12 pcs AIH24A/S insert must use CTI240 carbon inner tube at 5.2GPI to function properly
  • AIH24A - 18gn 7075-T5 aluminium
  • AIH24B - 30gn Brass (via C&T Dealer only)
  • AIH24C - 19gn 6061-T6 AL (via C&T Dealer only)
  • AIH24S - 28gn 303 Stainless

Notes:

• Clean arrow shaft with acetone before installation
• Use ACT(Arrow chamfering tool) for perfect self-concentric installation
• For best result use Firenock (AGUSSE) ultra slow set epoxy for installation
